CD/VCD Player Trainer
Categories: Educational TrainersFeatures: The complete circuit of a CD/VCD player is printed on a single P.C.B. The digital signal processing section is in assembled open out P.C.B. Explanation, Observation, Alignmen...
Product
Description
Features:
- The complete circuit of a CD/VCD player is printed on a single P.C.B.
- The digital signal processing section is in assembled open out P.C.B.
- Explanation, Observation, Alignment and adjustment of Internal and external possible due to single P.C.B.
- Easy identification of different parts and Mechanism at a glance
- Easy measurement of voltage and observation of waveforms at any point.
- A manual having practical detail is provided with the trainer
- The whole circuit of the CD/VCD Player is explained section wise in detail in the manual
Specifications:
- Power Supply: 230V AC, 50Hz
- Function Switches: Play/ Pause, Forward, Rewind, Stop, Program select/ Repeat, Skip Forward, Skip Reverse, Open/ Close, Tracks Select
- Display: Program, Time and Track status display
- Laser: Semiconductor Laser (780nm)
- Frequency Range: 5 - 20000Hz
- T.V. System: PAL and NTSC
- Audio Output: 200W PMPO (100W x 2 Channels)
- Speakers: 2 Nos.
- Modulation: EFM
- Quantization: 16 bit Linear
- CD Format: Audio CD, Video CD, MP3 CD can be played
- Output Sockets: Audio Out, Video Out, RF Out (Channel 2)
- Remote Controls: Play/ Pause, Forward, Rewind, Stop, Program select/ Repeat, Skip Forward, Skip Reverse, Open/ Close,Tracks Select
- Sampling Frequency: 44.1KHz
- Distortion: 5 to 10% for expanded P.C.B.
- Controls: Bass, Treble, and Volume
- Test points: 15
